Serial Box

Encodacam Serial Box V.4b

Our Serial box provides an easy "plug and play" way to set up your virtual
production system. We use rugged and reliable Lemo connectors that
connect to the moving encoder axes. It is a stable and “Broadcast Proven”
reliable tracking system in industry.


L*W*H 6.5"*6.3"*2.03" (160mm*160mm*51.5mm)
Weight 2 pounds (907g)
Encoders Standard: 6 channels with Index
Optional: 8 channels with Index
Lens

1 serial port with focus and zoom data
Canon and Fujinon (Broadcast) ENG lens ready

Sync Internal sync, Tri Level Sync or Black Burst sync
Protocol Kuper or Thoma
Rendering Brainstorm, VisRt, Orad, Ross Expression, Lightcraft Prevision, SolidTrack MotionBuilder
Streaming RS232 and RS422 , DB9 connector
Kuper: bi-directional communication
Thoma: simplex communication
Power AC: 110~240V
Optional: DC: 9~35 V



    General Lift International Inc.
  • Phone: + (310) 414 0717     Email: info@general-lift.com
  • Address: 111 Maryland Street, El Segundo, CA 90245, U.S.A.
